Description:
This is a nice entry-level high-quality piezo, pre-wired with leads to save you having to solder the leads on yourself. 27mm is a great size for installing in cigar box guitars, foot stompers, and other home-made instruments. They can also be used for custom pickup arrangements in more traditional stringed and percussion instruments. Some builders claim that the larger-diameter piezo responds better to bass tones, while others claim that the size of the piezo doesn't really matter. Try several sizes and see for yourself! An electric pick-up is a sure-fire way to take your cigar box guitar or other homemade instruments to the NEXT LEVEL, and many builders report that their instruments are much more attractive to potential buyers if they include a pickup. So here is your
Technical Specifications:
- Plate Diameter: 27mm (1.06 inches)
- Element Diameter: 20mm (.787 inches)
- Plate Thickness: .54mm (.021 inches)
- Lead Length: ~50mm (1.96 inches)
- Plate Material: Brass Resonant Frequency (kHz): 4.6 +/- 0.5 kHz Resonant Impedance (ohm): 300 max.
- Capacitance (nF): 20.0 +/- 30% [1kHz]
Features :
- Great for Acoustic Guitar Pickups, cigar box guitars, drum triggers & more!
- 27mm outside diameter with pre-soldered 2-inch leads
- High-quality piezoelectric transducers manufactured by Murata
- See product specs and measurements in the description text below
- Can be wired in series or parallel to create contact pickup arrays
Package Included:
1 x 27mm Piezoelectric Disk
